Measuring range: 0.05-150m
Measuring accuracy: ±(2+5xD10̄ 5)mm
Measurement unit options: mm / in / ft
Specifications:
Parameter – LDM-40/60/70/80/100/150
Measuring range – 0.05-150m
Measuring accuracy – ±(2+5xD10̄ 5)mm
Measurement unit options – mm / in / ft
Laser class – II
Laser type – 635nm, ≤1mw
Automatic laser off – 20s
Automatic power off – 150s
Automatic backlight – yes
Delay measurement – yes
Continuous measurement Max./Minn. measurement Area measurement Volume measurement – yes
Staking-out – yes
Pythagorean measurement Addition/subtraction/area Volume addition/Subtraction – yes
Display – LCD 4-line segment display, FSTN.
Max storage – 100units
Battery – AAA 2 x 1.5V
Storage temperature – -20°C ~ +60°C
Operation temperature – 0°C ~ +40°C
Ingress protection – IP54
Dimensions and weight – 118X54X26.5mm, 125g.
